• Detex Detex ADVANTEX 30 Series
• 30 Series Parts Diagram

Detex Detex ADVANTEX 30 Series

Diagram List

30 Series Parts Diagram

Detex Detex ADVANTEX 30 Series

Products by Part Type

Exit Device General Parts

• Center Case Kits & Parts
  • 102353-1 Centercase Cover, Wide, 30 Series
  • 104601-1 Centercase Cover, Aluminum, Wide, 30 series
• Cover Plate Kits & Parts
  • 100408-9 Fillerplate, Subassembly, S&R, Less Dogging, LD, 30 series, 36”
  • 100194-9 Fillerplate, Subassembly, S&R, Hex Dogging, HD, 30 series, 36”
  • 100179-9 Fillerplate, Subassembly, S&R, Cylinder Dogging, CD, 30 series, 36”
• End Cap Kit & Parts
  • 100147 Endcap bracket for EC1 (ramped) endcap w/o battery holder
  • 101093 Endcap bracket for EC1 (ramped) endcap w/ battery holder
  • 104303 Endcap bracket for EC2 (flush) endcap w/o battery holder
  • 104636 Endcap bracket for EC2 (flush) endcap w/ battery holder
  • 101642-9 EC1 Ramped Endcap
  • 104304-9 EC2 Flush Endcap, Stainless Steel
  • 104612-1 EC2 Flush Endcap, Aluminum
• Dogging Parts
  • 100450 Hex Dogging Key
  • 100783 Cylinder Hex Nut
  • 102216-2 Hex Dogging Assembly
  • 102216 Cylinder Dogging Assembly
• Strikes
  • 103285-9 ANSI Strike Kit
  • 103294-9 ANSI Strike Kit, Flap Lip
  • 103286-9 Double Door Strike Kit, Short Open Back
  • 103289-9 Double Door Strike Kit, Long Open Back
