For use with Latch Retraction (ER)

Features

• Regulated and filtered DC power supply
• Simultaneous 12VDC auxiliary and 24VDC main output
• Battery charging circuit with PTC protection
• Fire alarm input for emergency fail-safe lock release
• Auto-resetting circuit protection
• Individual fused protection
• Low battery disconnect at 70% battery capacity
• Heavy-duty 18-gauge steel enclosure
• Class 2 outputs
• 2 Amp continuous output
• Field-selectable output configuration
• Status LEDs for system monitoring
• Easy field expansion options

Benefits

Reliable 12VDC & 24VDC Power Output

• • Provides continuous regulated and filtered power for access control systems and electric locks
  • Supports simultaneous 12VDC and 24VDC operation for flexible applications

Built for Access Control & Security Systems

• • Ideal for electric strikes
  • Compatible with magnetic locks
  • Supports electrified door hardware
  • Designed for access control panels and security door systems

Easy Installation & Flexible Configuration

• • Class 2 outputs simplify installation requirements
  • Easy mounting plate installation
  • Field-selectable outputs allow flexible system setup

Simple Maintenance & Troubleshooting

• • External status LEDs provide quick system diagnostics
  • On/Off switch allows easy inspection and servicing
  • Quick disconnect wiring reduces installation time

Enhanced Safety & Battery Protection

• • Fire alarm interface enables emergency fail-safe lock release
  • Battery charging circuit supports backup battery operation
  • Low battery disconnect protects batteries from deep discharge
  • Individual fused outputs improve system protection

Electrical Options

• BB - Battery Backup (Includes Battery Charging Circuit and 2 batteries)
• LT - Less Transformer (Requires 24VAC input)

Technical Information

• Input: 110VAC-240VAC, 50/60 Hz
• Class 2 Rated
• Battery Charger: 13.5/27VDC, 500mA
