For use with Delayed Egress (EE) and Access Control

Features

• Regulated and filtered DC power supply
• Simultaneous 12VDC auxiliary and 24VDC main output
• Battery charging circuit with PTC protection
• Fire alarm input for emergency fail-safe lock release
• Auto-resetting circuit protection
• Individual fused protection
• Low battery disconnect at 70% battery capacity
• Heavy-duty 18-gauge steel enclosure
• Class 2 outputs
• 2 Amp continuous output
• Field-selectable output configuration
• Status LEDs for system monitoring
• Easy field expansion options

Benefits

Continuous 12VDC & 24VDC Output

• • Provides regulated and filtered 12VDC and 24VDC power simultaneously for reliable access control operation.

Designed for Access Control & Electric Locks

• • Electric strikes
  • Magnetic locks
  • Electrified door hardware
  • Access control panels
  • Security door systems

Simplified Installation

• • Class 2 outputs may be wired directly to 115VAC input without conduit requirements
  • Easy mounting plate installation
  • Field-selectable outputs for flexible configurations

Easy Service & Maintenance

• • External LEDs allow quick troubleshooting without opening the enclosure
  • On/Off switch simplifies inspection and servicing
  • Quick disconnect cable wiring saves installation time

Reliable Battery Backup Protection

• • Integrated battery charging circuit ensures uninterrupted operation during power failures.

Auto-Sensing Input Voltage

• • 110VAC / 120VAC
  • Converts up to 220VAC / 240VAC
  • Includes dedicated 12VDC output compatibility for Detex access control products.

Electrical Options

• BB - Battery Backup (Includes Battery Charging Circuit and 2 batteries)
• LT - Less Transformer (Requires 24VAC input)

Technical Information

• Input: 115VAC, 50/60 Hz
• Class 2 Rated
• Battery Charger: 13.5/27VDC, 500mA
