Features

• Patented plastic template allows for foolproof alignment of internal magnetic door contact and accurate installation
• Tapered cover allows for installation on narrow stile doors
• Intelligent circuit senses th external magnet location automatically and sets the correct door handing
• Patented cam assembly automatically adjusts for different sizes of cylinders without use of spacers
• Alarm can only be silenced by proper control key
• 100 dB piezo alarm
• LED visual and audible arming indicators
• Modern graphics on cover to demonstrate key rotation and operation
• 9VDC battery operated with Low Battery Alert
• Key required to reset alarm
• Field selectable 2-minute auto rearm, if desired
• Field selectable status indicators, if desired

Benefits

•  Low cost, self-contained door alarm with piezo horn that sounds to warn unauthorized use of a door or gate
• Secure, tamper resistant housing
• Door or wall mount
• Quick, easy installation saves time and money

Mechanical Option

• SK1 Kit allows for wall mounting and includes (1) white MS-1039S door contact
• SK2 Kit allows for wall mounting and includes (2) white MS-1039S door contact
• SK3 Kit allows for wall mounting and includes (1) brown MS-1059S door contact
• SK4 Kit allows for wall mounting and includes (2) brown MS-1059S door contacts
• SK5 Kit allows for wall mounting and includes (1) grey MS-2049S door contact
• SK6 Kit allows for wall mounting and includes (2) grey MS-2049S door contact
• KS - Key Stop, factory installed
• SI - Status Indicator On
• 102644 - In-Swing Door Kit

Electrical Option

• Weatherized for use on gates or doors that are subjected to inclement weather

Technical Information

•  Machine and Self-Drilling Screws (Std)
•  Optional Sex Nuts or Security Torx Screws available
• Optional Cylinder Nut Wrench
