Detex Detex H90R / H90R5 Series

Diagram List

Detex H90R / H90R5 Series Parts Diagram

Detex Detex H90R / H90R5 Series

Products by Part Type

Exit Device General Parts

• Mullion Channel
  • 106075-1 Mullion Channel, H90R5 7 foot
  • 106075-4 Mullion Channel, H90R5 7 foot, 230X prep
  • 106076-1 Mullion Channel, H90R 7 foot
  • 106076-2 Mullion Channel, H90R 8 foot
• Top Fitting
  • 106079 Hurricane Mullion Top fitting, H90R5
  • 106092 Hurricane Mullion Top fitting, , H90R
• Base Fitting
  • 106078 Base fitting, Hurricane Mullion, H90R5
  • 106091 Base fitting, Hurricane Mullion, H90R
• Mullion Parts & Accessories
  • 106093 Mullion base affixment plate
  • 106071-2 Concrete floor anchor, 3/8 diameter
  • 106074 Frame spacer block
• Screw Packs
  • 106087 Set screw, 1/4-20 x 5/16
