Schlage B663 Classroom Deadbolt
Diagram List
Products by Part Type
Deadbolt General Parts
- Lock Assembly
- 10-094 Flat Square Corner Strike With Metal Box, 2-3/4" x 1-1/8"
- 10-112 Metal dust box and 3 screws
- 12-618 Rose & Classroom Turn Assembly
- 12-631 Deadbolt
- 22-644 Deadbolt Cylinder for B660 and B663, 1-3/8" to 2-1/2"
- 36-066 Trim Ring, 1/8"
- 36-068 Security Insert, 1/8"
- B520-298 Philips Head Machine Cylinder Retainer
- B600-018 Mounting Plate for Rose and Turn
- B600-017 Security Shield
- B600-066 Philips Head Machine Turn Screw
- B600-070, 7/8" Collar (trim ring) for 1-5/8" – 2-1/2" door (standard)
- B600-100 Philips Oval Head Machine Mounting Screw, 1/4"-28 x 1-15/16"
- C603-897 Philips Flat Head Combination Screw
- R525-256 Screw Pack
- Trim
- Screws
- Cylinders
- Keys
- 35-100 Key Blank, 5-pin, Standard bow, Embossed (50 Pack)
- 35-130 Key Blank, 5-pin, Standard bow Unembossed (50 Pack)
- 35-131 Key Blank, 6-pin, Standard bow, Unembossed (50 Pack)
- 35-056 Control Key Blank, Standard bow, Embossed (50 Pack)
- 35-102 Emergency Key Blank, Standard bow, Embossed (50 Pack)
- 35-140 Key Blank, 5-Pin, Large Bow, Embossed (50 Pack)
- 35-141 Key Blank, 6-Pin, Large Bow, Embossed (50 Pack)
- 35-143 Key Blank, 5-Pin, Access Bow, Embossed (50 Pack)
- 35-144 Key Blank, 6-Pin, Access Bow, Embossed (50 Pack)
