Schlage Commercial Hardware Parts B581 Door Bolt with Trim

Diagram List

Lock Assembly

Schlage Commercial Hardware Parts B581 Door Bolt with Trim

Products by Part Type

Deadbolt General Parts

• Lock Assembly
  • 10-094 Flat Square Corner Strike With Metal Box, 2-3/4" x 1-1/8"
  • 10-112 Metal dust box and 3 screws
  • 12-288 Deadbolt
  • B302-041 Rose & Turn (D111)
  • B520-662 Screws
  • B520-086 Philips Oval Head Machine Screw
  • B600-018 Mounting Plate for Rose and Turn
  • B600-041 Tailpiece
  • B600-066 Philips Head Machine Turn Screw
  • C603-897 Philips Flat Head Combination Screw
  • R525-256 Screw Pack
• Trim
  • B302-041 Rose & Turn (D111)
  • B600-018 Mounting Plate for Rose and Turn
• Screws
  • B600-066 Philips Head Machine Turn Screw
  • C603-897 Philips Flat Head Combination Screw
  • R525-256 Screw Pack
  • B520-662 Screws
  • B520-663 Screws
  • 61-504 Combination Screw Pack, 2x B520-663 & 4x C603-897 & 2x B600-066 & 1x B600-018
  • 61-505 Combination Screw Pack
