General Electric Strikes Parts

• Box Assemblies

  • 111743, 6111, 6113, 6213 12VDC FS Box Assembly
  • 111744, 6111, 6113, 6213 12VDC FSE Box Assembly
  • 111745, 6111, 6113, 6213 24VDC FS Box Assembly
  • 111746, 6111, 6113, 6213 24VDC FSE Box Assembly
  • 111747, 6111, 6113, 6213 12VDC FS DS Box Assembly
  • 111748, 6111, 6113, 6213 12VDC FSE DS Box Assembly
  • 111749, 6111, 6113, 6213 24VDC FS DS Box Assembly
  • 111750, 6111, 6113, 6213 24VDC FSE DS Box Assembly
  • 112772, 6111, 6113, 6213 12VDC FS DS-LC Box Assembly
  • 112773, 6111, 6113, 6213 12VDC FSE DS-LC Box Assembly
  • 112775, 6111, 6113, 6213 24VDC FSE DS-LC Box Assembly

• Solenoid Kit

  • 050237, 6100, 6200 Series Solenoid Kit 12VDC (FS & FSE)
  • 050239, 6100, 6200 Series Solenoid Kit 16 VDC (FS & FSE)
  • 050240, 6100, 6200 Series Solenoid Kit 24VDC (FS & FSE)
  • 050699, 6100, 6200 Series Solenoid Kit 28VDC
  • 968713, Solenoid Spring
  • 964037, Solenoid Washer

• Faceplates

  • 970271, 6111 Faceplate
  • 970280, 6113 Faceplate

• Screw and Mounting Packs

  • 900870, 6111, 6113 Screw Package
  • 964070, Screw: 8-32 x 3/8" PPHMS

• Spring Kit

  • 050942, 6111/13, 6213, 6221/23 Spring Kit

• Misc. Parts

  • 900347, 6113 Frame Insert Package
  • 990132, Connector
  • 900344, DS Tripper Extension & Connector
  • 970384, DS Tripper Extension
  • 010055, 6111, 6113 Shim for blade stop applications
  • 050749, 6100, 6200 (9100) Filler Bracket Kit
  • 964019, #8 Ext. Tooth Lock Washer

Electric Strike Options

• EB - Entry Buzzer

  • 050242, Entry Buzzer (FSE application only)

• DS / DC-LC - Dual monitor switch

  • 050011, 6100, 6200 DS Replacement Kit Type A – Standard Back Box
  • 050015, 6100, 6200 DS Replacement Kit Type B – Special Back Box
  • 050016, 6100, 6200 DS-LC Replacement Kit Type A – Standard Back Box
  • 050018, 6100, 6200 DS-LC Replacement Kit Type B – Special Back Box
  • 113232, 6100, 6200 Series DS-LC Switch and Clip Assembly
  • 970384, DS Tripper Extension
  • 900344, DS Tripper Extension & Connector

• FS/FSE Conversion

  • 090591, FS Slider (All 6100 and 6200 Series models except 6211WF/6212WF/6221/6223)
  • 090798, FSE Slider (All 6100 and 6200 Series models except 6211WF/6212WF/6221/6223)

• VAC/VDC Rectifier Kit

  • 010057, 12 VAC to 12 VDC Rectifier Kit
  • 010058, 24 VAC to 24 VDC Rectifier Kit
