Trim Parts By Function

• NL (Night Latch) Function

  • 050140, 230/990DT x 330/350 1-3/4" Dr
  • 050141, 230DT x 330/350 Screw Package 2-1/4" Door
  • 050156, 210/230 Tailpiece Guide Lead Pkg/10
  • 956760, 880 Series Hex Stud
  • 963579, 880NL/DT 12-24 x 3/8" UFPHMS
  • 965226, 880-R Cylinder Collar
  • 968201, 210/230 Cylinder Retaining Cup
  • 972466, 880 / 990 Pull Grip, 626 Finish

• DT (Dummy trim) Function

  • 956760, 880 Series Hex Stud
  • 963579, 880NL/DT 12-24 x 3/8" UFPHMS
  • 965226, 880-R Cylinder Collar

• TP (Thumbpiece) Function

  • 050526 CD/SS Cylinder Lock Nut Package
  • 956760, 880 Series Hex Stud
  • 965226, 880-R Cylinder Collar
  • 969903, 230TP Cam
  • 969904, 230TP Slider
  • 969906, 230TP Locking Cam
  • 969909, 230TP Compression Spring
  • 969908, 230TP Locking Cam Latch
  • 969910, 230TP Thumbpiece
  • 972466, 880 / 990 Pull Grip, 626 Finish
  • 970979, 210K/L Spindle Shaft

• TP-BE (Thumbpiece, Blank) Function

  • 956760, 880 Series Hex Stud
  • 969903, 230TP Cam
  • 969904, 230TP Slider
  • 969910, 230TP Thumbpiece
  • 972466, 880 / 990 Pull Grip, 626 Finish
  • 970979, 210K/L Spindle Shaft

• L (Lever) Function

  • 090103, 210K Wave Spring Washer Pkg/10
  • 050156, 210/230 Tailpiece Guide Lead Pkg/10
  • 050526 CD/SS Cylinder Lock Nut Package
  • 900894, 230L Tailpiece Auxiliary
  • 050611, 230L Shear Pin Kit w/ Retaining Pin*
  • 971249, 230L Cylinder Collar
  • 050813, 230L Lever Cam*
  • 971497, 230L Locking Plunger
  • 971245, 230L Stud
