Picture of Von Duprin

SKU: DE5300

Von Duprin DE5300 Logic Controller, For Use with Delayed Exit Devices

Von Duprin DE5300 delayed egress system control module

Von Duprin

SKU: DE5300

Von Duprin DE5300 Logic Controller, For Use with Delayed Exit Devices

In stock

DE5300 Delayed Egress system is used in conjunction with a magnetic lock and contains all control units auxiliary locking, local alarm and remote signaling outputs

The Von Duprin DE5300 is designed for controlled egress applications when used in conjunction with a magnetic lock. It meets both life safety and security needs, as well as the requirements of NFPA101 for “Special Locking Arrangement” and IBC “Special Egress-Control Devices”. All control inputs, auxiliary locking, local alarm and remote signaling outputs are self-contained in the DE5300 assembly.
Numerous field configurable options allow the device to be customized for the specific code or application requirements. The standard DE5300 sounds an alarm and keeps the door secured for 15 seconds following an exit attempt with immediate release upon fire.

$1,651.00
$1,073.15
minus minus

Price Books

Frequently Asked Questions

What is the Von Duprin DE5300?
The DE5300 is a delayed egress system designed for controlled egress applications using a magnetic lock and a Von Duprin RX-LC exit device. It is commonly installed on narrow stile doors where a standard Chexit device is not practical.
What devices work with the DE5300?
The DE5300 is designed to work with compatible Von Duprin RX-LC exit devices and Schlage magnetic locks as part of a controlled egress system.
Does the DE5300 support fire alarm integration?
Yes. The DE5300 includes fire alarm input, access control input, alarm outputs, and configurable release delays for code-compliant installations.
Is the DE5300 used in healthcare facilities?
Yes. Delayed egress systems such as the DE5300 are commonly used in healthcare, memory care, behavioral health, and other facilities requiring controlled egress while meeting life safety requirements.
