Key Features

• Designed for use with Detex Exit Control Locks
• Supports outswinging double-door applications
• Compatible with wood, metal, and glass doors
• Case-hardened steel locking bolt
• Interchangeable pin design
• Stainless steel spring for instant lock bolt release
• Durable cast zinc alloy housing
• Reversible for left-hand or right-hand door installations
• No mortise required for installation
• Includes complete mounting kit
• Compact and durable construction for commercial environments

Benefits

Converts Single Exit Control Systems for Double Doors

• • Allows Detex Exit Control Locks to be effectively used on double-door exit openings while maintaining controlled security.

Automatic Emergency Release

• • When the active leaf is opened using the exit control lock, the DDH-2250 automatically disengages, enabling both doors to open for emergency evacuation.

Flexible Installation

• • Can be mounted on either the left or right door, simplifying installation requirements and inventory management.

Fast and Simple Installation

• • No mortising is required, reducing installation time and labor costs.

Durable Security Construction

• • Features a case-hardened steel locking bolt and heavy-duty zinc alloy housing for long-lasting reliability.

Reliable Emergency Egress

• • The stainless steel spring mechanism provides immediate lock bolt release for smooth operation during emergency situations.

Dimension

7 1/8" long x 2 1/4" deep x 2 7/8" high
