Features

• • ADA-compliant low energy automatic door operator
  • Supports push and pull door configurations
  • Quiet and smooth automatic operation
  • Reverse-on-obstruction safety technology
  • Adjustable delayed activation for vestibule applications
  • Push & Go activation capability
  • Power-close assistance for secure latching
  • Adjustable closing speed
  • Heavy-duty commercial construction
  • Compatible with access control and locking systems
  • Easy-access maintenance enclosure
  • Low-voltage ON/OFF/HOLD switch
  • Plug-in 115VAC power connection

Benefits

Accessibility Benefits

• • Provides ADA-compliant access for handicap applications
  • Improves accessibility in commercial facilities
  • Supports touchless and automatic entry solutions

Commercial Benefits

• • Ideal for medium to high-traffic buildings
  • Reduces manual door wear and operational strain
  • Integrates easily with security and access control systems

Maintenance & Installation Benefits

• • Hanger plate design enables faster installation
  • Easy-access enclosure simplifies maintenance
  • Reduced service calls due to heavy-duty construction

User Experience Benefits

• • Smooth and quiet door operation
  • Safer entry with obstruction detection
  • Convenient manual Push & Go activation

Technical Specifications

Power Requirements

• • 115VAC 60Hz 6 amps

Motor Specifications

• • 115VDC rectified motor
  • 1/8 HP motor
  • 60:1 gearbox

Door Compatibility

• • Supports doors up to 300 lbs
  • Push reveal depth up to 11”
  • Pull reveal depth up to 2.5”

Enclosure

• • 7” height x 4.5” depth
  • Aluminum extrusion housing
  • Approximate weight: 100 lbs

Mechanical Options

Length Option

• • 39.5" – Fits above most 36" doors
  • 45.5" – Fits above most 42" doors
  • 52" – Fits above most 48" doors

Handing Option

• • Left Hand Push (LH Push)
  • Right Hand Push (RH Push)
  • Left Hand Pull (LH Pull)
  • Right Hand Pull (RH Pull)
