The Schlage 194555261907 is the OEM L9580 Motorized Latch Retraction Chassis with LX (Latchbolt Monitor Switch) for the L Series mortise lock, documented in the Schlage Motorized Latch Retraction Data Sheet (doc 116154) and the L9000 Mortise with Motorized Latch Retraction Installation Instructions (doc 48124648). The chassis provides the L9580 storeroom function with motorized latch retraction, ships less single cylinder, includes the LX Latchbolt Monitor Switch, and is furnished with Allegion Connect - Schlage's factory-installed Molex connector system for simplified installation and field maintenance. ANSI A156.13 Level 1 security rated. Available (3-4 weeks).

What the Schlage L9580 Function Does

The L9580 is the electrified storeroom function in the Schlage L Series Motorized Latch Retraction catalog. The base behavior is the standard storeroom function: the outside lever is always locked from the corridor side, requiring a key or authorized credential for outside entry at all times. The inside lever is always free for immediate egress regardless of the lock state.

The Motorized Latch Retraction (MLR) layer adds remote electric latch retraction. When a valid credential is presented at a connected card reader, fob reader, or PIN pad, the motor in the chassis retracts the latch bolt, allowing the authorized user to push or pull the door open without using a key. This is the primary integration point with access control systems in secure storeroom applications - pharmaceutical storage, IT server rooms, secure evidence rooms, restricted access corridors, and controlled campus buildings where keyless access logging and card-based access management are required.

The outside lever can still accommodate a conventional cylinder for mechanical override and authorized key entry when the access control system is offline or during a power failure. The "Less Single Cylinder" designation on this chassis means the cylinder is not factory-installed - the facility provides and installs the Schlage cylinder type that matches their key system.

Schlage Motorized Latch: The LX Latchbolt Monitor Switch

The "w/ LX" designation confirms this chassis includes a Latchbolt Monitor Switch. The LX is an embedded microswitch that reports the real-time position of the latch bolt to the access control panel or building security system. The switch changes state when the latch retracts and again when the latch re-extends after the door closes.

Access control systems use LX data for three purposes. First, confirmation of authorized access: a valid credential plus an LX state change confirms that entry actually occurred, not just that a credential was presented. Second, forced access detection: if the latch retracts without a valid credential at the reader, the access control system logs the event as a forced entry. Third, door security verification: the LX confirms the latch is extended and the door is secured in the latched position, which is different from the door position sensor (which only confirms the door leaf is closed).

Per the official Schlage MLR Data Sheet: the L9580 with LX is rated to ANSI A156.13 Level 1 security and Endurance Level I. The LX switch electrical rating is 2A at 30V DC, resistive.

Schlage L9580 Chassis: Allegion Connect Wiring System

From the official Schlage L9000 Motorized Latch Retraction Installation Instructions (doc 48124648): "The L9510, L9580, L9582, L9692 EL/EU, L9695 EL/EU, and L9696 EL/EU are furnished with Allegion Connect, a factory-installed Molex connector system that provides simplified installation and maintenance."

Allegion Connect means all electrical connections at the chassis use factory-installed Molex connectors rather than terminal block or wire-nut field connections. Field wiring connects to the chassis via the matching Molex connector at the installation point. When servicing the chassis, the connector unplugs cleanly without cutting wires. The Allegion Connect CON-KIT provides field replacement connectors and terminals for maintenance.

The L9580 is available in 12 finishes: 605, 606, 609, 612, 613, 619, 622, 625, 626, 629, 630, and 643e.
