What is the primary function of the Schlage 10-025-1316?

It provides the door frame engagement point for the latch or bolt on compatible Schlage lock installations.

What size is the Schlage 10-025-1316 ANSI strike?

The ANSI strike measures 1-1/4" x 4-7/8".

Does the Schlage 10-025-1316 include a strike box?

No. The Schlage 10-025-1316 is a ANSI strike with no box.

Which Schlage lock series are compatible with the 10-025-1316 ANSI strike?

The Schlage 10-025-1316 ANSI strike is compatible with AD-Series, CO-Series, and B250 locks.

Is the Schlage 10-025-1316 an OEM replacement part?

Yes. It is a genuine Schlage OEM replacement part.

Schlage 10-025-1316 ANSI Strike|Security Parts

Name: Schlage 10-025-1316 ANSI Strike (Schlage)
SKU: 10-025-1316
Price: 15.43 USD
Availability: InStock

Schlage 10-025-1316 is a replacement ANSI strike used with compatible AD-Series, CO-Series, NDE Series and B250 locks. Designed for installation at the door frame, the strike provides the engagement point for the lock’s latch or bolt as part of the door assembly. The 1-1/4" x 4-7/8" strike is supplied without a box and is intended for servicing compatible Schlage commercial lock installations.

We are your trusted source for commercial door hardware, security hardware, electronic access control products, and OEM replacement parts.

Manufacturer: Schlage
Part Number: 10-025-1316
Product Type: ANSI Strike
Product Series: AD-Series, CO-Series, B250 Series, NDE Series

Primary Function: Provides the door frame engagement point for the lock latch or bolt

Application: Compatible Schlage commercial lock installations
Strike Size: 1-1/4" x 4-7/8"

Lip Length: 1-3/16"

Box: No box

OEM Part: Yes
